Emergency Rescue drone payload Solutions

Professional emergency rescue payload solutions for industrial UAV platforms, designed for disaster response, aerial lighting, material delivery, public safety operations, and complex rescue missions in hazardous or hard-to-reach environments.

Talk to Our Team

Applications

  • Support fast deployment in disaster zones where ground access is limited or unsafe.

  • Assist with aerial lighting, material transport, and operational support in mountain or remote rescue missions.

  • Deliver rescue supplies, tools, and lightweight mission materials to designated locations.

  • Support temporary lighting, broadcasting, and field coordination for emergency and security tasks.

Huanxin UAV emergency rescue payload solutions are designed for a wide range of rapid-response and public safety missions. These payloads support aerial lighting, material transport, fixed-point delivery, rope-descending operations, and remote broadcasting, helping improve efficiency and operational safety in urgent and complex rescue environments.

Why Choose Huanxin Emergency Rescue Payloads

  • Built for Industrial UAV Platforms
    Designed for professional UAV integration in demanding emergency and rescue missions.

  • Multiple Mission Functions
    Supports lighting, delivery, transport, rappelling, release, and broadcasting operations.

  • Modular and Flexible Integration
    Payload systems are designed for adaptable installation and field deployment.

  • Reliable Rescue Performance
    Developed for use in hazardous, remote, and hard-to-access operational environments.

  • Improved Mission Efficiency
    Helps reduce response time and improve on-site operational effectiveness.

  • Broad Payload Portfolio
    Provides multiple rescue support tools for different public safety and disaster scenarios.

How to Choose the Right Emergency Rescue Payload

Different rescue missions require different payload capabilities. Lighting systems are suitable for night operations and low-visibility environments. Release and delivery devices are better for fixed-point drop and emergency material deployment. Transport boxes support routine rescue logistics, while rappelling systems are designed for rope-based rescue support. Loudspeakers are ideal for field broadcasting, warning, and command coordination.

  • For Night Rescue Operations
    Choose searchlights and lighting modules.

  • For Fixed-Point Delivery
    Choose payload release devices and drop systems.

  • For Rescue Material Transport
    Choose material transport boxes and delivery modules.

  • For Rope-Based Rescue Support
    Choose powered rappelling devices.

  • For On-Site Broadcasting and Command
    Choose UAV loudspeaker systems.

UAV Searchlight Specification Table
Product Input Voltage Rated Power Net Weight Tilt Angle Luminous Flux Switch Input Signal
UAV Searchlight
UAV Searchlight
 22 ~ 60 V 65 W 604 g 0° ~ 90° 10000 LM PWM
UAV Lighting Module Specification Table
Product Color Temperature Brightness Beam Angle Input Voltage Rated Power Light Module Weight
UAV Lighting Module
UAV Lighting Module
 5500 K 54000 LM 60° DC 24–75 V 400 W 180 g (excluding cable)
Light Payload Release Device Specification Table
Product Power Supply Method Product Weight Release Count Supply Voltage Control Method Maximum Operating Current Maximum Suspended Payload Operating Temperature
Light Payload Release Device
Light Payload Release Device
 Powered by UAV 450 g 2 times 24 V PWM Pulse Control 1.2 A 10 kg -20°C to 60°C
UAV Material Transport Box Specification Table
Product Power Supply Method Power Connector Supply Voltage Maximum Operating Current Dimensions Control Method
UAV Material Transport Box
UAV Material Transport Box
 Powered by UAV XT30 24 V 1.2 A Subject to actual dimensions PWM Pulse Control
Powered Rappelling Device Specification Table
Product Operating Voltage Weight Maximum Payload Maximum Cable Length Maximum Cable Retraction / Extension Speed Operating Temperature Counterweight Functions
Powered Rappelling Device
Powered Rappelling Device
 48–80 V 3 kg 60 kg 30 m 15 m/min -25°C to 70°C 2 kg (automatic unhook after landing) One-touch quick release, landing-triggered unhook, top-contact protection, cargo weighing
Fire Bomb Release Device Specification Table
Product Dimensions Max Payload per Hook Standard Hook Quantity Device Weight Supply Voltage Quick-Release Support Control Method Release Method
Fire Bomb Release Device (DJI Compatible)
Fire Bomb Release Device (DJI Compatible)
 308.7 × 191.7 × 132.5 mm 60 kg 4 1.97 kg 24 V 3-second quick installation, one-touch quick release Remote controller button control Sequential electronic control (single drop or multiple drops, freely configurable)
UAV Loudspeaker Specification Table
Product Weight Rated Power Power Input Maximum Power Operating Temperature Tilt Angle Effective Broadcast Range Broadcast Mode
UAV Loudspeaker (DJI Compatible)
UAV Loudspeaker (DJI Compatible)
 750 ± 5 g 45 W 12–80 V 30 W -25°C to 50°C 0°–90° 650 m Real-time voice broadcast, audio file playback
UAV Searchlight Specification Table
Product Weight Total Power Luminous Flux Operating Mode Supply Voltage Warning Light Function Quick Release Luminous Efficiency
UAV Searchlight (DJI Compatible)
UAV Searchlight (DJI Compatible)
 750 g 136 W 16000 LM Steady On / Flashing 12–80 V Red and blue flashing on/off Supports twist-lock quick release and hot swapping 125 lm/W (128 W)
Customized product information is for reference only. For detailed specifications and technical parameters, please contact the Huanxin UAV team.
