Industrial Drone Payload Solutions

Huanxin provides professional industrial drone payload solutions for UAV platforms used in aerial cleaning, delivery, release, inspection, monitoring, spraying, stabilized mounting, and mapping missions.

Our payload range includes high-pressure cleaning kits, water intake devices, flame spray devices, gas detection modules, drop release systems, paper drop devices, water flow velocity meters, spraying kits, payload gimbals, LiDAR scanning systems, and high-altitude cleaning systems. These payloads help industrial drones complete complex field operations in hard-to-reach, elevated, hazardous, or large-area environments.

Talk to Our Team
industrial drone payload for aerial cleaning mission

Applications

  • An industrial drone payload can support high-pressure cleaning, aerial spraying, façade maintenance, solar panel washing, and high-altitude surface cleaning. Payload options include UAV high-pressure cleaning kits, spraying kits, water intake devices, and high-altitude cleaning systems.

  • For delivery and release missions, industrial drone payload systems can support fixed-point dropping, paper delivery, material delivery, emergency supply release, and specialized aerial payload deployment. Payload options include 4-position drop release systems and UAV paper drop devices.

  • Industrial drones can carry sensing payloads for environmental monitoring, gas detection, water monitoring, and infrastructure inspection. Payload options include UAV gas detection devices and water flow velocity meters.

  • For mapping, survey, and heavy-payload stabilization, industrial drone payload solutions can support LiDAR scanning, stabilized payload mounting, and high-precision mission equipment integration. Payload options include 15 kg payload gimbals, 50 kg payload gimbals, and UAV LiDAR scanning systems.

Huanxin UAV industrial drone payload solutions are designed for a wide range of mission scenarios, including aerial cleaning, material delivery, infrastructure inspection, environmental monitoring, industrial sensing, and mapping operations. These systems help improve efficiency, flexibility, and field performance in complex and hard-to-reach environments.

Why Choose This Industrial Payload Range

  • Built for Professional UAV Platforms
    Huanxin industrial drone payload systems are designed for integration with professional UAV platforms used in demanding industrial missions.

  • Multiple Payload Functions
    The payload range supports cleaning, spraying, release, delivery, sensing, inspection, stabilization, mapping, and high-altitude maintenance tasks.

  • Flexible Payload Integration
    Modular structures and mission-oriented designs help improve compatibility across different industrial drone applications.

  • Suitable for Complex Field Environments
    These payloads are developed for hard-to-reach, elevated, hazardous, and large-area working environments where traditional equipment may be difficult to deploy.

  • Scalable Product Range
    The page includes lightweight sensing modules, delivery and release systems, 30L cleaning and spraying payloads, 15 kg and 50 kg gimbal systems, and UAV LiDAR scanning equipment.

How to Choose the Right Industrial UAV Payload

Different industrial missions require different payload configurations. The right industrial drone payload should be selected according to the application scenario, payload weight, UAV platform capacity, power supply, mounting method, control signal, operating height, and field environment.

  • For Cleaning Missions
    Choose high-pressure cleaning kits, spraying kits, water intake devices, or high-altitude cleaning systems. These payloads are suitable for surface cleaning, high-rise façade maintenance, solar panel washing, and industrial facility cleaning.

  • For Drop and Delivery Tasks
    Choose drop release systems or paper drop devices. These payloads support fixed-point release, emergency delivery, paper deployment, and material dropping missions.

  • For Environmental or Industrial Monitoring
    Choose gas detection devices or water flow velocity meters. These payloads help industrial drones collect field data in hazardous, remote, or difficult-to-access environments.

  • For Stabilized Heavy Payload Integration
    Choose 15 kg or 50 kg payload gimbal systems. These payloads support stabilized mounting for heavier mission equipment and industrial tools.

  • For Survey and Mapping Tasks
    Choose UAV LiDAR scanning systems. These payloads are suitable for mapping, terrain survey, infrastructure inspection, and data collection missions.

Industrial Drone Payload Product Range

Huanxin offers a broad range of industrial drone payload products for different UAV mission requirements. The following payload systems can be selected according to application type, payload capacity, control method, installation structure, and working environment.

UAV High-Pressure Cleaning Kit Specification Table
Product Water Tank Capacity Spray Rod Material Extendable Length High-Pressure Pump Voltage High-Pressure Pump Weight High-Pressure Pump Pressure
UAV High-Pressure Cleaning Kit
UAV High-Pressure Cleaning Kit
 30 L Aluminum Alloy 1.5–3 m 48 V 2.5 kg Start: 0.25 MPa, Stop: 1.8 MPa
UAV Water Intake Device Specification Table
Product Dimensions Power Capacity Weight
UAV Water Intake Device
UAV Water Intake Device
 120 × 70 × 80 mm 30 W 1000 mL 684 g (water intake device only)
1.5 kg (including water collection bucket)
UAV Flame Spray Device Specification Table
Product Compatible Fuel Ignition Method Aiming Method Control Method Status Indication Control Signal Rated Power Spray Distance
UAV Flame Spray Device
UAV Flame Spray Device
 #92, #95, #98 gasoline High-frequency high-voltage arc ignition DJI remote controller + crosshair DJI PSDK remote ignition Voice prompt / RGB light strip PWM, SBUS 40 W 7 m (no wind)
UAV Gas Detection Device Specification Table
Product Detection Principle Supply Voltage Transmission Method Operating Temperature Operating Humidity Number of Detectable Gases Detectable Gases
UAV Gas Detection Device
UAV Gas Detection Device
 Compatible with electrochemical, laser, PID photoionization, infrared, semiconductor, and other detection methods 12–24 V RS485 / Wireless Data Transmission / Wireless 4G -20°C to 50°C 15–95% RH, non-condensing 8 CO, CH4, H2, O3, H2S, NH3, C7H8, smoke mist (optional as required)
4-Position Drop Release Specification Table
Product Material Dimensions Weight Power Supply Hook Spacing Control Signal Single Hook Payload Capacity Standard Hook Quantity
4-Position Drop Release
4-Position Drop Release
 6061 Aluminum Alloy, Carbon Fiber, Stainless Steel 263 × 76 × 900 mm (adjustable length) 1.35 kg–1.5 kg Built-in lithium battery, 5 V 220 mm PWM, SBUS 30 kg 4
UAV Paper Drop Device Specification Table
Product Interface Type Control Method System Power Compatible Paper Paper Capacity Paper Output Speed Paper Output Time Operating Temperature
UAV Paper Drop Device
UAV Paper Drop Device
 SKYPORT V2.0 / E-PORT / TYPE-C Pilot 20 W Standard A5 Printing Paper Up to 400 sheets 5–7 sheets per second Adjustable from 0 to 50 s -20°C to 60°C
Water Flow Velocity Meter Specification Table
Product Dimensions Weight Operating Frequency Sensor Type Data Display Data Transmission Video Transmission Output Power
Water Flow Velocity Meter
Water Flow Velocity Meter
 200 × 175 × 155 mm 570 g 24 GHz Millimeter-Wave Radar Mobile Phone, PC Browser, Remote Controller UAV Link, Built-in 4G Module UAV Link, Remote Controller Live Streaming 13 dBm (Flow Velocity) / 20 dBm (Water Level)
UAV Spraying Kit Specification Table
Product Product Dimensions Spray Rod Length Tank Capacity Spraying Range Power Supply Pump Flow Rate
UAV Spraying Kit
UAV Spraying Kit
 2040 × 349 × 250 mm 1.5 m 30 L 15–20 m 12–14 S 14 L/min
15 kg Payload Gimbal Specification Table
Product Material Dimensions Weight Max Payload Protection Rating Operating Temperature Input Voltage Input Power Max Power Max Torque Control Accuracy Axis Mounting Method
15 kg Payload Gimbal
15 kg Payload Gimbal
 Aluminum Alloy + Carbon Fiber 227 × 175 × 94 mm 2.1 kg ± 20 g ≤ 15 kg IP4X -20°C to 45°C 15–26 V 12 V / 2.5 A (Max) 300 W 3 N·m ±0.08° Pitch Axis, Roll Axis Quick-Release Module (3s Quick Mount / One-Click Release)
50 kg Payload Gimbal Specification Table
Product Dimensions Weight Payload Capacity Protection Rating Operating Temperature Input Voltage Input Power Max Power Max Torque Control Accuracy Communication Cable Axis Mounting Method Roll Axis Range Pitch Axis Range
50 kg Payload Gimbal
50 kg Payload Gimbal
 350.7 × 278 × 120 mm 4 kg 50 kg IP4X -20°C to 45°C 15–24 V 12 V / 2.5 A (Max) 380 W 50 N·m ±0.08° 20-core Cable Roll Axis, Pitch Axis 3 s Quick Installation / One-Click Quick Release ±169° ±45°
UAV LiDAR Scanning System Specification Table
Product Absolute Accuracy Point Density Weight Dimensions System Power Consumption Operating Temperature Power Supply Measurement Range Point Rate Field of View Ranging Accuracy Camera Resolution Data Update Rate
UAV LiDAR Scanning System
UAV LiDAR Scanning System
 10 cm @ 150 m 50 pts/m² @ 150 m @ 10 m/s 1.1 kg 14.4 × 10.9 × 12 cm 20 W -20°C to 55°C 12–24 V Up to 300 m 192,000 pts/s (Triple Echo) 360° / 40.3° 0.5 cm 26 MP 200 Hz
UAV High-Altitude Cleaning System Specification Table
Product Spray Arm Material Hose Material Nozzle Angles Spray Angle Adjustment Hose Connection Type Hose Length Rated Working Pressure Burst Pressure Mounting Plate
UAV High-Altitude Cleaning System
UAV High-Altitude Cleaning System
 Carbon Fiber High-Pressure Explosion-Proof Hose 0°, 15°, 25° Quick-Change Nozzles Adjustable Horizontal Swing 4-Point Quick Connector 100 m (Customizable) 8–10 MPa 22 MPa Compatible with FC30 to T100 Series UAVs
Customized product information is for reference only. For detailed specifications and technical parameters, please contact the Huanxin UAV team.

FAQ

  • An industrial drone payload is a mission device or equipment system carried by a UAV to complete a specific industrial task. Depending on the application, an industrial drone payload can be used for cleaning, spraying, delivery, release, gas detection, water monitoring, inspection, mapping, or stabilized equipment mounting.

  • The right industrial drone payload depends on your mission type, payload weight, UAV platform capacity, power supply, mounting method, control signal, operating height, and working environment. For example, cleaning missions may require a high-pressure cleaning kit or spraying payload, while mapping missions may require a LiDAR scanning payload.

  • Yes. Industrial drone payloads can be customized according to UAV platform type, payload capacity, installation structure, control method, power supply, mission equipment, and application scenario. Customization may be required for special cleaning systems, release devices, sensing modules, gimbals, LiDAR systems, or high-altitude working tools.

  • Industrial drone payload options include high-pressure cleaning kits, water intake devices, flame spray devices, gas detection modules, drop release systems, paper drop devices, water flow velocity meters, spraying kits, payload gimbals, LiDAR scanning systems, and high-altitude cleaning systems.

  • For cleaning missions, suitable payloads include high-pressure cleaning kits, water intake devices, spraying kits, and high-altitude cleaning systems. These payloads can support façade cleaning, solar panel washing, industrial roof cleaning, and high-altitude surface maintenance.

  • For mapping and survey missions, a UAV LiDAR scanning system is suitable. It can support terrain survey, mapping, infrastructure inspection, and industrial data collection. Stabilized payload gimbals may also be used when the mission requires stable mounting for heavier equipment.
